1kVA HYBRID SYSTEM

Description

System Specifications:

• Inverter Rating: 1kVA (800W continuous output)
• Battery Capacity: 1 x 150Ah 12V (or equivalent storage)
• Solar Panel Array: ~500W (2 x 250W panels)
• Charge Controller: 30A MPPT
• Backup Options: Grid or Generator

Appliances Supported:

This system is ideal for light usage, supporting the following:

1. Lighting: Up to 8 LED bulbs (10W each) for ~6 hours.
2. TV: 32-inch LED TV for ~4–6 hours.
3. Laptop/Phone Charging: Multiple devices (4–6 devices simultaneously).
4. Small Fans: 1–2 fans (50W each) for ~4–5 hours.
5. Wi-Fi Router: Continuous operation (~10W).
