3kVA HYBRID SYSTEM

Description

System Specifications:

• Inverter Rating: 3kVA (2.4kW continuous output)
• Battery Capacity: 2 x 200Ah 12V (or equivalent storage)
• Solar Panel Array: ~1500W (6 x 250W panels)
• Charge Controller: 60A MPPT
• Backup Options: Grid or Generator

Appliances Supported:

This system can handle moderate loads:

1. Lighting: Up to 12 LED bulbs (10W each) for ~8 hours.
2. TV: 1–2 LED TVs (32–50 inches) for ~6–8 hours.
3. Refrigerator: Small or medium-sized fridge (~150W) for ~6–8 hours.
4. Fans: 2–3 fans (50W each) for ~6 hours.
5. Laptops/Charging: Multiple laptops and devices.
6. Microwave/Kettle: Occasionally (~1000W for 10–15 minutes per use).
