5kVA HYBRID SYSTEM

Description

System Specifications:

• Inverter Rating: 5kVA (4kW continuous output)
• Battery Capacity: 4 x 200Ah 12V (or equivalent storage)
• Solar Panel Array: ~3000W (12 x 250W panels)
• Charge Controller: 80A MPPT
• Backup Options: Grid or Generator

Appliances Supported:

This system is designed for larger households or small offices:

1. Lighting: Entire home lighting (~15–20 LED bulbs).
2. TV: Multiple TVs (up to 55 inches) for ~10 hours.
3. Refrigerator: Full-sized refrigerator (~200–250W) for ~10 hours.
4. Water Pump: Up to 0.5HP for periodic use.
5. Fans and ACs: 3–4 fans or a small air conditioner (~1000W) for ~6 hours.
6. Kitchen Appliances: Regular use of kettles, microwaves, or blenders.
7. Computers and Networking: Office equipment for prolonged hours.
